You can download drawings and technical information if you scroll to the right of the table.
You can download drawings and technical information if you scroll to the right of the table.
|
Model name
|
Sensor Size
|
Focal Length
|
F-Number
|
Working Distance
|
Distortion
|
Weight
|
Images
|
Specification
|
CAD data
|
Technical data
|
date | resolution | image circle |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M0828-MPX | 2/3 | 8mm | 2.8 | 2024-01-11 14:18:04 | 16MP | 11.8 | |||||||
| M1228-MPX | 2/3 | 12mm | 2.8 | 2024-01-10 16:24:34 | 16MP | 11.8 | |||||||
| M1628-MPX | 2/3 | 16mm | 2.8 | 2024-01-09 16:26:07 | 16MP | 11.8 | |||||||
| M2528-MPX | 2/3 | 25mm | 2.8 | 0.1m - Inf. | 0.07%(y=5.5) | 83g | 2024-01-07 16:51:23 | 16MP | 11.8 | ||||
| M3528-MPX | 2/3 | 35mm | 2.8 | 0.15m - Inf. | 0.1%(y=5.5) | 89g | 2024-01-06 16:56:53 | 16MP | 11.8 | ||||
| M5028-MPX | 2/3 | 50mm | 2.8 | 0.2m - Inf. | 0.04%(y=5.5) | 85g | 2024-01-05 16:48:46 | 11.8 | |||||
| M7538-MPX | 2/3 | 75mm | 3.8 | 0.25m - Inf. | 0.01%(y=5.5) | 89g | 2024-01-04 16:50:16 | 16MP | 11.8 |
You can download Computar’s Industrial Lenses General Catalogue.
Click on the link below and fill in the required information.
These are catalogue for individual Computar products.
